    EHB30 - Hydraulic Breaker

    New
    Working height 2,477 kg
    Applicable carrier weigh 26 - 35 ton
    Tool shank diameter 150 mm
    Download Brochure EHB30-Catalog.pdf
    Contact

    HIGHLIGHTS

    • Reduces internal torsion stress to increase fastener life.
    • No rigid side bolts
    • Low maintenance cost
    • Extremely durable welded structure
    • Reduces noise
    • Hammer is completely protected and quieter
    • Perfect sealed enclosure by dust protector & seal plugs(premium series only)
    • Fewer components
    • Wide and appropriate openings
    • Optimized by high grade steel and heat treatment
    • Optimal damping system made of high quality elastomer
    • Minimizing recoil shock induced by impact
    • Reduces noise and vibration
    • Lessens pressure fluctuation
    • Less damage on carrier’s pump
    • Noise insulation
    • Dust protection, Easy maintenance
    • Maximizes impact energy
    • Minimizes recoil
    • Eliminates mechanical springs
    • Special heat-treated and hardened piston
    • Resisting wear and abrasion

    Specifications

     ITEM  UNIT EHB30
     Working weight
    		  kg 2,477
     Required oil flow
    		 lpm 170  - 240
     Operating pressure  bar 165 - 185
     Blow frequenc
    		   Low speed mode  bpm 310 - 490
      High speed mode  bpm 400 - 680
      Low speed mode  joule 6,100
      High speed mode  joule 4,200
     Tool shank diameter  mm 150
     Applicable carrier weigh  mm 26 - 35
